POWER INDUCTOR SERIES

1.FEATURES

- High temperature materials allow operation in ambient temperatures up to 180°C.
- Soldered self-leaded construction for excellent solderability.
- Very low DCR values and excellent current handling

2.APPLICATIONS

- DC/DC converter, LNB(Set top box ,LED, Mobile)

3.SPECIFICATIONS

Power Inductors for Power Circuits
Image	Series	Part number	L x W(mm)	Height(MAX)	Data sheet
	SPY Series	SPY5022	5 X 5	2.5
	SPM Series	SPM3215	3 X 3	1.7
		SPM3220	3 X 3	2.2
		SPM4532	4.5 X 4	3.35
		SPM6050	5.8 X 5.2	4.65
		SPM8050	7.8 X 7	5.15
		SPM10060	10 X 9	5.55
	SPC Series	SPC6025	6 X 6	2.5
		SPC7030	7 X 7	3.0
		SPC7040	7 X 7	4.0
		SPC7060	7 X 7	6.0
		SPC10040	10 X 10	4.0
		SPC12060	12 X 12	6.0
		SPC12080	12 X 12	8.0
Pass the AEC-Q200 Certification Test (SPE201610,3012 4020,5020 제외)	SPE Series	SPE201610H	2.0*1.6	1.0
		SPE201610	2.1*1.7	1.05
		SPE252012H	2.5*2.0	1.25
		SPE252012	2.5*2.0	1.25
		SPE3012	3 X 3	1.21
		SPE3015	3 X 3	1.8
		SPE4020	4 X 4	2.3
		SPE4030	4 X 4	3.3
		SPE5020	5 X 5	2.3
		SPE5040	5 X 5	4.3
		SPE6028	6 X 6	3.1
		SPE6045	6 X 6	4.8
		SPE8040	8 X 8	4.3
	SPS Series	SPS6028	6 X 6	2.8
		SPS7032	7 X 7	3.2
		SPS7045	7 X 7	4.5
		SPS7060	7 X 7	6.0
		SPS10050	10 x 10	5.2
		SPS10050M	10 x 10	5.2
		SPS12060	12 X 12	6.0
		SPS12060M	12 X 12	6.0
		SPS12080	12 X 12	8.0
		SPS12080M	12 X 12	8.0
		SPS15060M	15 X 15	6.0
		SPS15080M	15 X 15	8.0
Pass the AEC-Q200 Certification Test (SPH8040,13050 제외)	SPH Series	SPH201610	2.6 X 1.6	1.0
		SPH252010	2.5 X 2.0	1.0
		SPH3020	3.4 X 3.2	2.0
		SPH4020	4.6 X 4.2	2.0
		SPH5030	5.5 X 5.2	3.0
		SPH7030	7.1 X 6.6	3.0
		SPH7040	7.1 X 6.6	4.0
		SPH8040	8.8 X 8.2	3.8
		SPH10040	11.5 X 10.3	4.0
		SPH10050	11.5 X 10.3	5.0
		SPH13040	13.8 X 12.6	4.0
		SPH13050	13.8 X 12.6	5.0
		SPH13060	13.8 X 12.6	6.0
		SPH17070	17.15 X 17.15	7.0
Pass the AEC-Q200 Certification Test	SPL Series	SPL7045	7.3 X 7.3	4.5
		SPL10080(Mn)	10.2 X 10.2	8.0
		SPL10080(Mn)*1	10.2 X 10.2	8.0
		SPL12060	12.35 X 12.35	6.3
		SPL12060*1	12.35 X 12.35	6.3
		SPL12080(Ni)	12.35 X 12.35	8.3
		SPL12080(Ni)*1	12.35 X 12.35	8.3
		SPL12080(Mn)	12.35 X 12.35	8.3
		SPL12080(Mn)*1	12.35 X 12.35	8.3
